Antenna Connector Adapter SMA(f) to U.FL(m)

Product code: AM-67-CAUS
Producer: SECTRON

Antenna Connector Adapter SMA(f) to U.FL(m)

Connector adaptor SMA (f) to U.FL (m) is used to connect devices that have different types of connectors.

4.26incl. VAT (21%) / pc

excl. VAT 3.52 € / pc

Price from 10 pieces 3.20 €

Price from 100 pieces 2.88 €

In stock
i
- +
Add to compare

If the customer is not registered for VAT, the rate according to his country of residence will be added.

Detailed description

Connector adaptor SMA (f) to U.FL (m)

Connector adaptor is used to connect devices that have different types of connectors. This adaptor consists of connectors SMA (f) and U.FL (m).

Connector specifications SMA:

These are high-frequency connectors with screw connection mechanism. The characteristic impedance of the connector is 50 Ohm and the operating frequency range up to 18 GHz. There are two types of SMA connectors, namely SMA and RP-SMA. The connection and disconnection of the connectors is guaranteed for up to 500 cycles. Temperature range is -65 °C to +165 °C. Most of the current cellular routers are equipped with SMA connectors for connecting Wi-Fi / 2G / 3G / LTE / GPS antennas terminated by proticates. It is also used as a standard connector in RF measuring technology. They are characterized by high reliability, durability, high mechanical stability and optimal electrical properties.

Connector specifications U.FL:

U.FL connectors are used in cases where there is very little space for connecting / interconnecting RF components eg in wireless communication devices, electronic measuring instruments, mobile phones, GPS and wireless LANs. Gold-plated central contact of the U.FL connector improves its properties. The characteristic impedance of the connector is 50 Ohm and the operating frequency ranges up to 6 GHz.

Parameters

4.26incl. VAT (21%) / pc

excl. VAT 3.52 € / pc
