Telit Cinterion BGS2-W Rel.4.5
The M2M Cinterion BGS2-W Rel.4.5 Wireless Module offers full voice capabilities, high-speed GPRS data DL: max.85.6 kbps, UL: max 42.8 kbps and best-in-class low power consumption and the lowest power consumption in its class.
The module delivers Quad-Band GSM/GPRS (2G) with advanced SSL encryption for IP-based services, jamming detection, an analog and digital audio interface, and generic flash access to the module's internal memory.
This BGS2-W module is designed for use anywhere in the world.
Key features:
• Dimensions: 27.6 x 18.8 x 2.7 mm
• Cast: LGA
• Technology: GSM Quad-Band: 850/900/1800/1900 MHz
• Frequency: GSM/GPRS
• Temperature range: -40 °C to + 90 °C
• EDGE data transfers: No
• GPRS Data Streams: Multislot Class 10
• CDMA: No.
• CSD: Yes
• Audio analog/digital interface: 1x / x
• USB Interface: No.
• Java embedded: No.
• SMS: Yes
• Fax: Yes
• TCP/IP: Yes
• Antenna connector: via LGA pins
• Multi GPIO's (digital): Yes, 6x
• RoHS and EuP compliant
Telit company merged with Thales Gemalto, thereby created a major global player. The newly formed Telit Cinterion group is a major manufacturer of Cinterion® wireless modules and a leader in digital security and encryption in chip manufacturing. SECTRON is an European authorized distributor of this Telit Cinterion division.
Technical parameters can be found in the attached datasheet.
